14N73-16-16-L190-AV
DESCRIPTION:
14N73-16-16-L190 is a long bend hydraulic flange fitting designed for use with 1 inch 4SH hydraulic hose. It features a Code 61 flange connection and a long-radius bend configuration with an overall length of 190 mm, providing improved hose routing, reduced stress on the hose assembly, and reliable performance in high-pressure hydraulic systems.
TECHNICAL DESCRIPTION:
| Parameter | Description |
|---|---|
| Part Number | 14N73-16-16-L190 |
| Product Type | Long Bend Hydraulic Flange Fitting |
| Fitting Series | 4SH Hydraulic Hose Fitting |
| Hose Size | 1 Inch (DN25) |
| Hose Compatibility | EN 856 4SH Hydraulic Hose |
| Connection Type | Code 61 Flange |
| Flange Size | 1 Inch |
| Bend Type | Long Bend |
| Overall Length | 190 mm |
| Fitting Orientation | Bent Flange |
| Material | Carbon Steel |
| Surface Finish | Zinc-Plated / Corrosion-Resistant Coating (Typical) |
| Pressure Rating | As per hose and flange assembly specification |
| Sealing Method | O-ring Face Seal at Flange Connection |
| Application | High-Pressure Hydraulic Systems |
| Compatible Media | Hydraulic Oil, Mineral Oils, Industrial Fluids |
| Temperature Range | Dependent on hose specification and fluid used |
| Features | Long-radius bend, reduced hose stress, secure flange connection, high-pressure capability |
| Typical Applications | Hydraulic power units, construction equipment, mining machinery, industrial hydraulic systems |
