322H35-2995-482725C2
DESCRIPTION:
H Series is a indirect acting solenoid valves, normally closed and normally open, from 1/4" to 3/4", offering extremely robust design and different flow rates.
TECHNICAL DESCRIPTION:
| Function: | Normally open |
| Power Supply Voltage: | 24V DC |
| Media: | Air, Neutral Gases |
| Seal Material: | PUR |
| Port Size: | G 1/2 |
| Coil Power Consumption: | 9W |
| Maximum Operating Pressure: | 40 bar |
| Insulation Class: | H 180 °C |
| Coil Specifications Met: | CE - VDE - EAC |
| Electrical Connection: | 2 P + E plug according to EN 175301-803 type A (connector included) |
| Maximum Fluid Temperature: | 50 °C |
| Valve Type: | 2/2-Way |
| Actuation Type: | Pilot Operated |
| Port Type: | Pipe Mounting |
| Body Material: | CW 617N UNI EN 12165 |
| Seat Material: | Stainless Steel |
| Orifice Size: | 15 mm |
| Flow Coefficient 1: | 60 L/min |
| Flow Coefficient 2: | 3.6 m3/hour |
| Minimum Operating Pressure: | 1.5 bar |
| Minimum Fluid Temperature: | -10 °C |
| Coil Temperature Range: | -40 to 50 °C |
| Specifications Met: | - |
| ATEX Specifications Met: | n/a |
