421SNMSHA-8
Description: Parker R1 Hose ID 1/2 Inch,W.P.160 Bar
Technical Specification:
Hose I.D : 1/2lnch,12.7mm
Hose R.O.D; 18.2mm
Hose O.D: 20.7mm
Working Pressure: 2325psi,160bar
Minimum bend radius: 3.5lnch, 90mm
Approx weight: 0.30ibs/ft,0.44kg/m
Inner tube: Synthetic rubber
Reinforcement: One braids steel wire
Outer Cover: Synthetic rubber
Temp Range: -40° to 100°( -40°F to 212°F)
Impulse Cycles: specified -150000cycles,Tested upto-300000(@Full MBR)
