421SNPM-40PM
Description: Parker R1 Hose , Size - 2 1/2 Inch
Technical Specification
- Hose I.D : 2-1/2lnch / 60.3mm
- Hose R.O.D : 69.0mm
- Hose O.D : 75.0mm
- Working Pressure : 362psi / 25bar
- Minimum bend radius : 30lnch / 762mm
- Approx weight : 1.86lbs/ft / 2.77kg/m
- Inner tube : Synthetic rubber
- Reinforcement : One braids steel wire
- Outer Cover : Synthetic rubber
- Temp Range : -40° to 100°( -40°F to 212°F)
- Impulse Cycles : specified -150000cycles,Tested upto-300000(@Full MBR)
