7181-381
DESCRIPTION:
Heavy Duty Heater Hose is designed for use in heater and radiator systems in vehicles and industrial equipment in applications to 257°F and 65 psi, Series 7181
TECHNICAL DESCRIPTION:
| Minimum Operating Temperature: | -40 °F, -40 °C |
| Hose Inner Tube Material: | Ethylene Propylene Diene Monomer (EPDM), Black |
| Cover Material: | Ethylene Propylene Diene Monomer (EPDM) |
| Application: | Specialty |
| Media: | Coolants, Mild Chemicals - Check your fluid compatibility with our catalogue chart., Water (Hot Water) |
| Specifications Met: | SAE J20R3EC, Class D2 |
| Compatible Fitting: | n/a |
| Inside Diameter: | 3/8 inch, 9.5 mm |
| Hose Reinforcement Material: | 2 Plies of Textile |
| Package Type: | Reel |
| Outside Diameter: | 0.690 inch, 17.5 mm |
| Cover Color: | Black |
| Maximum Operating Temperature: | 257 °F, 125 °C |
| Weight: | 0.16 lb/ft, 0.24 kg/m |
| Standard Pack Qty (ft): | 600 |
| Maximum Working Pressure (psi): | 65 |
| Minimum Bend Radius: | 5 inch, 127 mm |
| Maximum Operating Pressure: | 65 psi, 4.5 bar |
| Hose I.D. (inch): | 3/8 |
