8.5020.D544.2500
DESCRIPTION:
The 8.5020.D544.2500 is a Sendix 5020 series incremental rotary encoder designed for industrial motion control and automation applications
TECHNICAL DESCRIPTION:
| Parameter | Specification |
|---|---|
| Part Number | 8.5020.D544.2500 |
| Product Series | Sendix 5020 |
| Device Type | Incremental Rotary Encoder |
| Measuring Principle | Optical Incremental |
| Resolution | 2500 Pulses Per Revolution (PPR) |
| Output Signals | A, B quadrature channels with reference signal (depending on configuration) |
| Supply Voltage | 10 to 30 VDC |
| Output Circuit | Push-Pull (HTL compatible) |
| Shaft Design | Hollow Shaft |
| Shaft Diameter | Typically 10 mm (as defined by D544 option code) |
| Protection Class | IP67 |
| Housing Material | Die-cast metal |
| Maximum Speed | Up to 6,000 rpm |
| Operating Temperature | -40°C to +85°C |
| Connection Type | Cable or connector version (depending on configuration code) |
| Mounting | Hollow shaft mounting with stator coupling |
| Direction Detection | Via quadrature A/B signals |
| Typical Applications | Motors, conveyors, packaging machines, automation equipment, servo systems |
