DT-500-MFMO-5
DESCRIPTION:
DT Series steel check valve
TECHNICAL DESCRIPTION:
| Cracking Pressure (psi): | 5 |
| Actuation Type: | Mechanical |
| Maximum Working Pressure (psi): | 4500 |
| Maximum Operating Pressure: | 4500 psi |
| Inlet Port Size (inch): | 3/4 - 16 UNF |
| Mounting Type: | Threaded |
| Outlet Port Size (inch): | 3/4 - 16 UNF |
| Maximum Operating Temperature: | 250 °F |
| Inlet Port Connection Type: | Male JIC 37 degree |
| Configuration: | N/A |
| Outlet Port Connection Type: | Male SAE O-ring Straight Thread |
| Minimum Operating Temperature: | -40 °F |
| Connection Type: | Male Flare JIC to Male ORB |
| Maximum Flow Rate: | N/A |
| Body Size: | 1/2 inch |
| Flow Direction: | N/A |
| Connection Size: | 3/4 - 16 UNF |
| Body Material: | Steel |
| Seal Material: | Metal & Elastomeric |
| Seat Type: | Metal seal |
