E121K67-4833713D
DESCRIPTION:
K Series is a full range of direct operated solenoid valves, from 1/8" to 1/2", offering many sealing materials and different flow rates.
Technical Specifications
| Specifications Met: | - |
| Valve Type: | 3/2 Way |
| Orifice Size: | 2,0 mm |
| Seal Material: | FKM |
| ATEX Specifications Met: | II 2 G Ex eb IIC T4 |
| Coil Specifications Met: | CE - EAC |
| Electrical Connection: | Cable gland or M20 x 1.5 "Ex eb" on screw terminals for wires up to 1.5 mm² |
| Coil Power Consumption: | 8W |
| Maximum Operating Pressure: | 7 bar |
| Power Supply Voltage: | 220-230V 50Hz |
| Port Size: | 1/4" G |
| Function: | Universal |
| Actuation Type: | Direct Operated |
| Port Type: | Pipe Mounting |
| Body Material: | CW 617N UNI EN 12165 |
| Media: | Air, Neutral Gases, Liquids |
| Seat Material: | Stainless Steel |
| Exhaust Orifice Size: | 2 mm |
| Flow Coefficient 1: | 2.5 L/min |
| Flow Coefficient 2: | 0.15 m3/hour |
| Minimum Operating Pressure: | 0 bar |
| Minimum Fluid Temperature: | -10 °C |
| Maximum Fluid Temperature: | 100 °C |
| Coil Temperature Range: | -40 +65 °C |
| Insulation Class: | F 155 °C |
